background image
Page 2 of 2
SUPER FLUX LED
BTF-37WHCS-XX-X
Absolute Maximum Ratings at Ta=25℃
Symbol
Parameter
Max.
Unit
PD
Power Rating
80
mW
VR
Reverse Voltage (IR=10µA)
5
V
IF
Continuous Forward Current
30
mA
IPF
Peak Forward Current (0.1 duty cycle @ 1kHz)
100
mA
Topr
Operating Temperature Range
–35 ~ + 80
℃
Tstg
Storage Temperature Range
–40 ~ + 100
℃
Lead Soldering Temperature [1.6mm (0.063inch) from body]
260℃ - max 5 seconds
Color and Brightness Selection
BTF-37WHCS-XX-X
Color Bin Selection
Brightness Bin Selection
White
Bin
X
Y
0.20
0.20
0.27
0.28
0.31
0.27
BW
(Bluish
White)
0.31
0.20
0.24
0.28
0.32
0.36
0.36
0.36
PW
(Pure
White)
0.36
0.28
0.29
0.36
0.38
0.45
0.42
0.45
YW
(Yellowish
White)
0.42
0.36
XX
All Range
Bin
Range(mcd)
R
1800~2500
S
2500~3500
T
3500~4900
X
1800~4900
DB LECTRO Inc. 3600 boul. Matte suite i Brossard Qc J4Y-2Z2 tel:(450)-444-1424 fax:(450)-444-4714 www.dblectro.com
