70 / 232 page  KSZ9567R DS00002329D-page 70 2017-2019 Microchip Technology Inc. 5.1 Global Registers This section details the device’s global registers. For an overview of the device’s entire register map, refer to Section 5.0, "Device Registers". For details on the device’s port registers, refer to Section 5.2, "Port Registers". 5.1.1 GLOBAL OPERATION CONTROL REGISTERS (0x0000 - 0x00FF) 5.1.1.1 Global Chip ID 0 Register 5.1.1.2 Global Chip ID 1 Register 5.1.1.3 Global Chip ID 2 Register 5.1.1.4 Global Chip ID 3 Register Address: 0x0000 Size: 8 bits Bits Description Type Default 7:0 Fixed Value RO 0x00 Address: 0x0001 Size: 8 bits Bits Description Type Default 7:0 Chip ID (MSB) RO 0x95 Address: 0x0002 Size: 8 bits Bits Description Type Default 7:0 Chip ID (LSB) RO 0x67 Address: 0x0003 Size: 8 bits Bits Description Type Default 7:4 Revision ID RO - 3:1 RESERVED RO - 0 Global Software Reset This bit dos not self-clear. Refer to the Switch Operation Register for another reset control bit. 0 = Normal operation 1 = Resets the data path and state machines, but not register values. R/W 0b |
|
