OUTER PACKAGING

The sealed reel is packed into a pizza box.

LABEL

Standard bar code labels for finished goods

The standard bar code labels are product labels and used for identification of goods. The finished goods are packed in final

packing area. The standard packing units are labeled with standard bar code labels before transported as finished goods to

warehouses. The labels are on each packing unit and contain Vishay Semiconductor GmbH specific data.

CARTON BOX DIMENSIONS in millimeters

THICKNESS

WIDTH

LENGTH

Pizza box (Panhead, Heimdall, and Belobog)

(taping in reels)

50

340

340

VISHAY SEMICONDUCTOR GmbH STANDARD BAR CODE PRODUCT LABEL (finished goods)

PLAIN WRITING

ABBREVIATION

LENGTH

Item-description

-

18

Item-number

INO

8

Selection-code

SEL

3

LOT-/serial-number

BATCH

10

Data-code

COD

3 (YWW)

Plant-code

PTC

2

Quantity

QTY

8

Accepted by

ACC

-

Packed by

PCK

-

Mixed code indicator

MIXED CODE

-

Origin

xxxxxxx+

Company logo

LONG BAR CODE TOP

TYPE

LENGTH

Item-number

N

8

Plant-code

N

2

Sequence-number

X

3

Quantity

N

8

Total length

-

21

SHORT BAR CODE BOTTOM

TYPE

LENGTH

Selection-code

X

3

Data-code

N

3

Batch-number

X

10

Filter

-

1

Total length

-

17

Thickness

Width

22127

Length
