7

Maximum rating

Stressing the device outside the ratings listed in Table 4 may cause permanent damage to the device. These

are stress ratings only, and operation of the device at these, or any other conditions outside those indicated in

the operating sections of this specification, is not implied. Exposure to absolute maximum rating conditions for

extended periods may affect device reliability.

Table 4. Absolute maximum ratings

Symbol

Parameter

Min.

Max.

Unit

-

Ambient operating temperature

-40

130

°C

TSTG

Storage temperature

–65

150

°C

TLEAD

Lead temperature during soldering

see note (1)

°C

IOL

DC output current (SDA = 0)

–

5

mA

VIO

Input or output range

–0.50

6.5

V

VCC

Supply voltage

-0.50

6.5

V

VESD

Electrostatic pulse (human body model)(2)

–

3000

V

1. Compliant with JEDEC Std J-STD-020 (for small body, Sn-Pb or Pb-free assembly), the ST ECOPACK 7191395

specification, and the European directive on Restrictions of Hazardous Substances (RoHS directive 2011/65/EU of July

2011).

2. Positive and negative pulses applied on different combinations of pin connections, according to ANSI/ESDA/JEDEC JS-001

(C1=100 pF, R1=1500 Ω).
