CUI DEVICES | SERIES: PT01 | DESCRIPTION: ROTARY POTENTIOMETER

date 08/05/2022 | page 7 of 8

cuidevices.com

MECHANICAL DRAWING (VERTICAL/SIDE MNT W/SLEEVE BUSHING, 10 MM HEIGHT)

units: mm [inch]

tolerance:

X≤10: ±0.3 mm

10<X≤30: ±0.5 mm

30<X≤100: ±1.0 mm

unless otherwise noted

ITEM DESCRIPTION

MATERIAL

PLATING/COLOR

A

base

PBT (UL94V-0)

black

B

shaft

PC (UL94V-0)

black

C

reed

nickel-zinc alloy

D

bracket

iron

bright tin

E

terminals

cold rolled steel

dark tin

10

(.394)

40 ° ±10 °

FULL CCW POSITION

3 PLCS.

0.8

(.031)

5.0

(.196)

7.4

(.291)

2.0

(.078)

3.3

(.129)

2.4

(.094)

3.5

(.138)

10.0

(.394)

5.5

(.217)

F

L ±

0.5

(.020)

6.8

(.268)

4.5

(.177)

6.8

(.267)

2 PLCS.

3 PLCS.

12 3

1.8

+0.2

-0.0

(.071

)

+0.008

-0.0

2 PLCS.

2.2

+0.2

-0.0

(.087

)

+0.008

-0.0

8.2

(.323)

5.0

(.197)

1.0

+0.2

-0.0

(.039

)

+0.008

-0.0

3.3

(.130)

Recommended PCB Layout

Top View

MOUNTING HARDWARE

M9X 0.75

(.030)

THICKNESS

0.4

(.016)

DIA.

9.1 ± 0.3

(.358 ± .012)

DIA.

15.0 ± 1.0

(.591 ± .039)

2.0 ± 0.2

(.079 ± .008)

11.0 ± 0.5

(.433 ± .020)

units: mm [inch]

Note:

Hex nut and washer supplied with threaded bushing version.

Additional Resources: Product Page | PCB Footprint
