P9242-R3/RB Datasheet
© 2019 Integrated Device Technology, Inc.
36
May 17, 2019
12.2 Recommended Coils
Table 26. Recommended Coil Manufactures
Output Power
Vendor
Part number
Inductance at 100kHz
DCR at 20°C
15W
SUNLORD
SWA53N53H30C11B
10µH
50mΩ
15W
TDK
WT525225-12F2-MA2-G
10.6µH
40mΩ
15W
WURTH
760308103102
10µH
55mΩ
12.3 Typical Application Schematic – P9242-R3-EVK included in WP15WBD-RK Kit
Note: The typical application schematic provides a basic guideline to understanding and building a functional medium-power wireless power
transmitter type MP-A2 as described in the WPC specifications. Other components, not shown on the typical application schematic, might be
needed in order to comply with other requirements, such as EMC or thermal specifications.
