AD9511

Rev. A | Page 47 of 60

Table 24 lists the AD9511 control registers by hexadecimal address. A specific bit or range of bits within a register is indicated by angle

brackets. For example, <3> refers to Bit 3, while <5:2> refers to the range of bits from Bit 5 through Bit 2. Table 24 describes the

functionality of the control registers on a bit-by-bit basis. For a more concise (but less descriptive) table, see Table 23.

Table 24. AD9511 Register Descriptions

Reg.

Addr.

(Hex)

Bit(s) Name

Description

Serial Control Port

Configuration

Any changes to this register takes effect immediately. Register 5Ah<0> Update Registers does not

have to be written.

<3:0>

Not Used.

<4>

Long Instruction

When this bit is set (1), the instruction phase is 16 bits. When clear (0), the instruction phase is 8 bits.

The default, and only, mode for this part is long instruction (Default = 1b).

<5>

Soft Reset

When this bit is set (1), the chip executes a soft reset, restoring default values to the internal

registers, except for this register, 00h. This bit is not self-clearing. A clear (0) has to be written

to it to clear it.

<6>

LSB First

When this bit is set (1), the input and output data is oriented as LSB first. Additionally, register

addressing increments. If this bit is clear (0), data is oriented as MSB first and register addressing

decrements. (Default = 0b, MSB first).

<7>

SDO Inactive

(Bidirectional

Mode)

When set (1), the SDO pin is tri-state and all read data goes to the SDIO pin. When clear (0), the

SDO is active (unidirectional mode). (Default = 0b).

Not Used

<7:0>

Not Used.

<7:0>

Not Used.

<7:0>

Not Used.

PLL Settings

<5:0> A Counter

6-Bit A Counter <5:0>.

<7:6>

Not Used.

<4:0> B Counter MSBs

13-Bit B Counter (MSB) <12:8>.

<7:5>

Not Used.

<7:0> B Counter LSBs

13-Bit B Counter (LSB) <7:0>.

<1:0>

Not Used.

<2>

LOR Enable

1 = Enables the Loss-of-Reference (LOR) Function; (Default = 0b).

<4:3>

Not Used.

<6:5> LOR Initial Lock

Detect Delay

LOR Initial Lock Detect Delay. Once a lock detect is indicated, this is the number of phase frequency

detector (PFD) cycles that occur prior to turning on the LOR monitor.

<6>

<5>

LOR Initial Lock Detect Delay

3 PFD Cycles (Default)

6 PFD Cycles

12 PFD Cycles

24 PFD Cycles

<7>

Not Used

<1:0> Charge Pump

Mode

<1>

<0>

Charge Pump Mode

Tri-Stated (Default)

Pump-Up

Pump-Down

Normal Operation
