AD8000
Rev. 0 | Page 10 of 20
–120
–110
–100
–90
–80
–70
–60
–50
–40
FREQUENCY (MHz)
1
10
100
SECOND HD
THIRD HD
VS = ±5V
VOUT = 2V p-p
G = –1
RL = 1kΩ
LFCSP
Figure 29. Harmonic Distortion vs. Frequency
0.01
0.1
1
10
100
1k
FREQUENCY (MHz)
1
0.1
10
100
1000
VS = ±5V
VIN = 0.2V p-p
RF = 432Ω
LFCSP
G = +1
OR G = +2
Figure 30. Output Impedance vs. Frequency
2.35
2.40
2.45
2.50
2.55
2.60
2.65
0
5
10
15
20
25
30
35
40
45
50
TIME (ns)
G = +2
G = +1
VS = 5V
RF = 432Ω
RS = 0Ω
RL = 100Ω
Figure 31. Small Signal Transient Response
FREQUENCY (MHz)
1
0.1
10
100
–75
–70
–60
–40
–30
–20
–15
–10
–50
–65
–45
–35
–25
–55
VS = ±5V
VIN = 2V p-p
RL = 100Ω
G = +1
RF = 432Ω
–PSRR
+PSRR
Figure 32. Power Supply Rejection Ratio (PSRR) vs. Frequency
FREQUENCY (MHz)
1
0.1
10
100
1000
–60
–40
–30
–50
–65
–45
–35
–25
–55
VS = ±5V
VIN = 1V p-p
RL = 100Ω
LFCSP
Figure 33. Common-Mode Rejection Ratio vs. Frequency
–0.150
–0.125
–0.075
0.025
0.075
0.125
0.150
0.175
–0.025
–0.100
0
0.050
0.100
–0.050
TIME (ns)
–0.175
0
5
10
15
20
25
30
35
40
45
50
G = +1
G = +2
VS = ±5V
RF = 432Ω
RS = 0Ω
RL = 100Ω
Figure 34. Small Signal Transient Response
