background image
AD8128
Rev. 0 | Page 5 of 12
PIN CONFIGURATION AND FUNCTION DESCRIPTIONS
PIN 1
INDICATOR
1
VIN+
2
VIN–
3
VGAIN
4
VPEAK
7VOFFSET
8VS+
6VOUT
5VS–
TOP VIEW
(Not to Scale)
AD8128
Figure 3. Pin Configuration
Table 4. Pin Function Descriptions
Pin No.
Mnemonic
Description
1
VIN+
Positive Equalizer Input
2
VIN−
Negative Equalizer Input
3
VGAIN
0 V to 1 V Broadband Gain Control
4
VPEAK
0 V to 1 V High Frequency Gain Control
5
VS−
Negative Power Supply
6
VOUT
Equalizer Output
7
VOFFSET
DC Offset Adjust
8
VS+
Positive Power Supply
EP
GND
Ground Reference and Thermal Pad (see Exposed Pad (EP) section).
