TX - R

Transko Electronics, Inc reserves the right to make changes to the product (s), service (s), and specification (s) described herein without notice. See “Terms of Sale” for details on our website.

■ SOLDER PATTERN

■ REFLOW PROFILE

■ PACKAGE DIMENSIONS

Unit : mm

Note: Consult factory for detail

Soldering

255 ±5°C

150 ±5°C

Pre-heating

<10 Sec

<120 Sec

170 ±5°C

■ PART NUMBERING GUIDE

Pin Configuration

1

N/C or Vc

2

GND

3

Output

4

VDD

Unit : mm

TX

3

R

25

J

TR

P

TAPE & REEL

TR:

1000/reel

Blank: Cut tape

05

10.000M

PULLABILITY (VTX option)

5:

±5.0 ppm min.

10:

±10.0 ppm min.

15: ±15.0 ppm min.

Call for Higher Pullability

FREQUENCY

M: MHz

OUTPUT

P: Clipped sine wave

R: CMOS

TYPE

TX: TCXO

VTX: VCTCXO

STABILITY

05: ± 0.5ppm *

10: ± 1.0ppm

15: ± 1.5ppm

20: ± 2.0ppm

25: ± 2.5ppm

30: ± 3.0ppm

50: ± 5.0ppm

XX: Two digit for

Stability

PACKAGE

SUPPLY VOLTAGE

3 :

3.3V

5.08

4

3

1

2

4

3

1

2

7.0±0.15

0.6

1.4

2.0

4.2

5.08

#1

2.2

0.3

OPERATING TEMP.

H: 0º to 50ºC

I: -10º to 60ºC

J: -10º to 70ºC

K: -20º to 70ºC

L: -30º to 70ºC

M: -40º to 85ºC

N: -30° to 75°C

* Available in selected operating temp. range
