background image
May 2006
Rev 2
1/10
10
Order codes
Part Number
Marking
Package
Packing
BUL804
BUL804
TO-220
Tube
BUL804
High voltage fast-switching NPN Power Transistor
General features
■
NPN Transistor
■
High voltage capability
■
Low spread of dynamic parameters
■
Minimum lot-to-lot spread for reliable operation
■
Very high switching speed
■
In compliance with the 2002/93/EC European
Directive
Description
The device is manufactured using high voltage
Multi-Epitaxial
Planar
technology
for
high
switching speeds and medium voltage capability.
It uses a Cellular Emitter structure with planar
edge termination to enhance switching speeds
while maintaining the wide RBSOA.
The device is designed for use as PFC in high
frequency ballast half Bridge voltage fed topology.
Applications
■
Electronic ballast for fluorescent lighting
■
Dedicated for PFC solution in half-bridge
voltage fed topology.
Internal schematic diagram
TO-220
1
2
3
www.st.com
