BA6208

LINEAR INTEGRATED CIRCUIT

UNISONICTECHNOLOGIESCO.,LTD

3 of 4

www.unisonic.com.tw

QW-R109-004,C

PARAMETER

SYMBOL

RATINGS

UNIT

Power Supply Voltage

18

V

Maximum Output Current

500

mA

DIP-8

500

mW

SIP-9

700

mW

Power Dissipation

SOP-8

450

mW

Operating Temperature

-20 ~ +60

°C

Storage Temperature

-55 ~ +125

°C

Note Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.

INPUT TRUTH TABLE

3pin (Ain)

2pin (Bin)

8pin (Aout)

7pin (Bout)

H

L

H

L

L

H

L

H

H

H

L

L

L

L

OPEN

OPEN

Note: HIGH level input is 2.0V or more.

LOW level input is 0.8V or less.

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP

MAX

UNIT

Output Saturation Voltage

1.6

V

High

2.0

V

Input Level Voltage

Low

0.8

V

Output Current

200

mA

Standby Supply Current

Ain=Low, Bin= Low

0.4

mA

Input High Level Current

400

µA

Note: A diode that absorbs at least 500mA is built in to give protection against surge currents with a pulse width of

10 ms and a duty ratio of 10% or less.
