The EtherNet/IP to Serial Linking Device allows you

to connect any serial device to your ControlLogix™

and CompactLogix™ PLC from Rockwell

Automation. The stand-alone Linking Device is less

expensive than an in-chassis-based solution, and

has even better integration to Studio 5000® from

Rockwell Automation.

EtherNet/IP™ to Serial Linking Device

In short:

EtherNet/IP Adapter Class

product which is tightly

integrated to Rockwell

Studio5000 allowing you

to connect serial devices to

Rockwell PLCs.

Connect devices that use:

RS232/422/485 interfaces

Modbus RTU

Rockwell DF1

Catalog number:

HMS-EN2SE-R

The EtherNet/IP to Serial Linking Device will:

•

Minimize costs when connecting serial devices to your PLC. More cost-

efficient than an in-chassi solution.

•

Allow you to easily retrofit existing serial devices.

•

Speed up configuration — Automated process inside Rockwell

Studio5000.

Technical highlights

•

Custom Add-On Profile: simplifies configuration and reduces

commissioning time, dynamically generates data structures. No need for

any ladder logic or Add On Instructions.

•

No hardware of software changes for the connected device.

•

Does not affect backplane performance (PLC execution time), even when

large amount of data is transferred to the Logix PLC.

•

EtherNet/IP Adapter Class product supporting announced-based DLR.

•

Supports serial RS232/422/485, Modbus RTU and DF1.

•

Automatically generates named and structured Studio 5000 controller

tags based on the configuration — no need for add-on instructions or

creating alias tags.

•

Connects up to 31 serial nodes.

•

ODVA, CE, UL, ATEX and Haz.Loc. certifications pending.

HMS provides a

full 3 year product

guarantee

The EtherNet/IP to Serial Linking Device from HMS integrates industrial devices communicating via RS232/422/485,

Modbus RTU and DF1 with a Rockwell PLC. You do all configuration in your familar Rockwell Studio 5000 environment.

All network and device

configuration is done

within Studio 5000.

See how it works at

www.encompass.hms-

networks.com

Integrated into

Studio5000
