AD8611/AD8612
Rev. A | Page 9 of 20
TEMPERATURE (°C)
0
–0.5
–4.5
50
100
0
50
VS = 3V
–3.0
–3.5
–4.0
–1.5
–2.0
–1.0
VS = 5V
–2.5
Figure 19. IGND vs. Temperature
TEMPERATURE (°C)
0
–3.0
–60
100
–40
–20
0
20406080
–0.5
–1.0
–1.5
–2.0
–2.5
VS = 3V
VS = 5V
Figure 20. ISY− vs. Temperature
TIME (2ns/DIV)
0V
VOUT
VIN
–VIN TRACE @ 10mV/DIV
VOUT TRACE @ 1V/DIV
V+ = 5V
TA = 25°C
Figure 21. Rising Edge Response
TIME (2ns/DIV)
0V
–VIN TRACE @ 10mV/DIV
VOUT TRACE @ 1V/DIV
VIN
VOUT
V+ = 5V
TA = 25°C
Figure 22. Falling Edge Response
TIME (4ns/DIV)
0V
VIN
VOUT
–VIN TRACE @ 10mV/DIV
VOUT TRACE @ 1V/DIV
V+ = 5V
TA = 25°C
Figure 23. Response to a 50 MHz, 100 mV Input Sine Wave
