AD8353
Rev. B | Page 16 of 16
OUTLINE DIMENSIONS
0.30
0.23
0.18
SEATING
PLANE
0.20 REF
0.80 MAX
0.65 TYP
1.00
0.85
0.80
1.89
1.74
1.59
0.50 BSC
0.60
0.45
0.30
0.55
0.40
0.30
0.15
0.10
0.05
0.25
0.20
0.15
BOTTOM VIEW
*
4
1
58
3.25
3.00
2.75
1.95
1.75
1.55
2.95
2.75
2.55
PIN 1
INDICATOR
2.25
2.00
1.75
TOP VIEW
0.05 MAX
0.02 NOM
12° MAX
EXPOSED PAD
Figure 43. 8-Lead Lead Frame Chip Scale Package [LFCSP_VD]
2 mm × 3 mm Body, Very Thin, Dual Lead
CP-8-1
Dimensions shown in millimeters
ORDERING GUIDE
Model
Temperature Range
Package Description
Package Option
Branding
AD8353ACP-R2
−40°C to +85°C
8-Lead LFCSP_VD
CP-8-1
JB
AD8353ACP-REEL7
−40°C to +85°C
8-Lead LFCSP_VD, 7" Tape and Reel
CP-8-1
JB
AD8353ACPZ-REEL71
−40°C to +85°C
8-Lead LFCSP_VD, 7" Tape and Reel
CP-8-1
0E
AD8353-EVAL
Evaluation Board
T
1 Z = Pb-free part.
© 2005 Analog Devices, Inc. All rights reserved. Trademarks and
registered trademarks are the property of their respective owners.
C02721–0–12/05(B)
