1996 Sep 18

4

Philips Semiconductors

Product specification

Fast soft-recovery

controlled avalanche rectifiers

BYW97 series

GRAPHICAL DATA

Fig.2

Maximum permissible average forward

current as a function of tie-point temperature

(including losses due to reverse leakage).

handbook, halfpage

0

200

4

0

2

MLB523

100

I F(AV)

(A)

T

( C)

o

tp

3

lead length 10 mm

1

Device mounted as shown in Fig.11.

Fig.3

Maximum permissible average forward

current as a function of ambient temperature

(including losses due to reverse leakage).

0

200

2.0

0

0.4

1.6

MLB524

100

I F(AV)

(A)

T

( C)

o

amb

0.8

1.2

Fig.4 Maximum repetitive peak forward current as a function of pulse time (square pulse) and duty factor.

0

20

110

MLB527

40

t

(ms)

p

I FRM

(A)

10

30

= 0.05

δ

0.1

0.2

0.5

1
