173 03/01

2-Line Filters

B84142-A*-R

for Converters and Power Electronics

Power line filters for single-phase systems

Rated voltage 250 V~, 50/60 Hz

Rated current 10 to 60 A

Construction

s Two-line filter

s Metal case

Features

s High insertion loss

s Easy to install

s Degree of protection: IP 201)

s Space-saving design

s Design complies with

EN 133 200, UL 1283, CSA 22.2 No.8 1986

s Optimized for long motor cables

and operation under full load

s EN, UL and CSA approval pending

Applications

s Frequency converters for motor drives, e.g.

– elevators

– conveyor systems

– pumps

– traction systems

– HVAC systems (heating, ventilation and air conditioning)

s Power supplies

Terminals

s Safe-to-touch terminal blocks

Marking

Marking on component:

Manufacturer’s logo, ordering code,

rated voltage, rated current,

rated temperature, date code

Minimum marking on packaging:

Manufacturer’s logo, ordering code

1) In accordance with IEC 60529: 1989; EN 60529: 1991; DIN VDE 0470-1
