The device is controlled and monitored by registers accessed through the I²C serial interface. These

registers provide device control functions and can be read to determine device status and acquire

device data.

The register set is summarized below. The values of all registers and fields that are listed as reserved

(gray) or are not listed must not be changed at any time. Two-byte fields are always latched with the

low byte followed by the high byte. The

“Name” column illustrates the purpose of each register by

highlighting the function associated to each bit. The bits are shown from MSB (D7) to LSB (D0).

Note: After power on reset the following commands have to be written prior accessing other registers:

Write 44h to register 6Fh

Write 20h to register 6Eh

Write 00h to register 6Fh

10.1

Figure 26:

Addr

Name

<D7>

<D6>

<D5>

<D4>

<D3>

<D2>

<D1>

<D0>

Configuration Registers

0x38

CFG_MISC

LED_WAI

T_OFF

WAIT_CYC

LE_ON

SW_RST

0x39

CFG_LED_MUL

LED_MULT [4:0]

0x3A

reserved

0x3B

reserved

0x3C

TEMP_COMPD

TEMP_COMPDAC [7:0]

0x3D

LED_WAIT

LED_WAIT [7:0]

0x3E

CFG_PINMAP

INT_PINMAP [2:0]

INT_INVE

GPIO_PINMAP [2:0]

RAM Configuration

0x40

CFG_RAM_0

…

32 Byte for programming the configuration data into the internal RAM

0x5F

CFG_RAM_31

Enable Register

0x60

ENABLE

LTF_MODE [1:0]

LED_AUTO [1:0]

SYNC_E

TSD_EN

LTF_EN

PON

Configuration Registers

0x61

LTF_ITIME_L

LTF_ITIME [7:0]
