SSM2306

Rev. 0 | Page 7 of 16

0.001

0.01

0.1

100

10k

100k

FREQUENCY (Hz)

VDD = 3.6V

AV = 18dB

RL = 8Ω, 33µH

0.5W

0.125W

0.25W

Figure 9. THD + N vs. Frequency, VDD = 3.6 V, RL = 8 Ω, AV = 18 dB

0.001

0.01

0.1

100

10k

100k

FREQUENCY (Hz)

VDD = 3.6V

AV = 18dB

RL = 4Ω, 33µH

0.25W

0.5W

Figure 10. THD + N vs. Frequency, VDD = 3.6 V, RL = 4 Ω, AV = 18 dB

0.001

0.01

0.1

100

10k

100k

FREQUENCY (Hz)

VDD = 2.5V

AV = 18dB

RL = 8Ω, 33µH

0.075W

0.25W

0.125W

Figure 11. THD + N vs. Frequency, VDD = 2.5 V, RL = 8 Ω, AV = 18 dB

0.001

0.01

0.1

100

10k

100k

FREQUENCY (Hz)

VDD = 2.5V

AV = 18dB

RL = 4Ω, 33µH

0.125W

0.5W

0.25W

Figure 12. THD + N vs. Frequency, VDD = 2.5 V, RL = 4 Ω, AV = 18 dB

4.0

4.5

5.0

5.5

6.0

6.5

7.0

7.5

2.5

3.0

3.5

4.0

4.5

5.0

5.5

SUPPLY VOLTAGE (V)

ISY FOR BOTH CHANNELS

RL = 8Ω, 33µH

RL = 4Ω, 33µH

NO LOAD

Figure 13. Supply Current vs. Supply Voltage, No Load

0.10.20.30.40.50.60.70.8

SHUTDOWN VOLTAGE (V)

VDD = 5V

VDD = 2.5V

VDD = 3.6V

Figure 14. Supply Current vs. Shutdown Voltage
