Coil former

Material:

GFR thermosetting plastic (UL 94 V-0, insulation class to IEC 60085:

H

max. operating temperature 180 °C), color code black

Solderability: to IEC 60068-2-20, test Ta, method 1 (aging 3): 235 °C, 2 s

Resistance to soldering heat: to IEC 60068-2-20, test Tb, method 1B: 350 °C, 3,5 s

Winding:

see “Processing Notes”, page 156

Squared pins

Sections

mm

µΩ

Terminals

Ordering code

1

20,3

28,7

48,6

8

B65846-W1008-D1

FEP0028-C

View in mounting direction

Ground ø1,3+0,2

ø1+0,2

Hole arrangement

0,2

6+0,15

18,7

0,3

0,7

0,45

including pin 1

Marking of pin row

0,1

0,7

B65846

Accessories

EP 17
