SE2425U

RangeCharger

Preliminary Information

165-DST-01 Rev 1.3 Apr-05-2006

Confidential

3 of 10

QA040506

Absolute Maximum Ratings

Operation in excess of any one of above Absolute Maximum Ratings may result in permanent damage. This device is

ESD sensitive. Handling and assembly of this device should be at ESD protected workstations.

Symbol

Parameter

Min.

Max.

Unit

Supply Voltage

-0.3

+4.2

V

Enable Voltage

-0.3

V

IN

RF Input Power

-

0

dBm

Case Temperature Range

-40

+85

°C

Storage Temperature Range

-40

+150

°C

Maximum Junction Temperature

-

+150

°C

DC Electrical Characteristics

°C, f = 2.45 GHz, as measured on SiGe Semiconductor’s

SE2425U-EV1 evaluation board unless otherwise noted.

Symbol

Parameter

Min.

Typ.

Max.

Unit

Supply Voltage

2.7

3.3

3.6

V

-

110

-

mA

-

28

-

mA

-

81

-

mA

-

123

-

mA

Current sunk by EN pin (logic high)

-

-

1

µA

Current sunk by MODE pin (logic high)

-

-

1

µA

Logic High Voltage

2.0

2.8

3.3

V

Logic Low Voltage

0

-

0.8

V

-

1

10

µA
