SEALED, ILLUMINATED ROCKER SWITCHES

SEALED

ROCKERS

K3

SNAP-IN PANEL MOUNTING, ATTRACTIVE & RUGGED FOR WET & DUSTY ENVIRONMENTS

.42

1.89

1.83

.25 TYP.

.39

.25

.39

.44

1.02

TERMINAL ID

LABEL

SIDE "A"

SIDE "C"

SWITCH SHOWN IN POSITION "A"

SWITCH SHOWN WITH TERMINAL BARRIERS

CONNECTOR KEY FEATURE OPTIONAL

TERMINAL BARRIER

(OPTIONAL)

LIGHT TERMINAL LOCATION

IND IN "A"

(LED POLARITY NOTED)

ANODE (+)

CATHODE (-)

LIGHT TERMINAL LOCATION

IND IN "C"

(LED POLARITY NOTED)

ANODE (+)

CATHODE (-)

POSITION "A" STATIONARY

TERMINAL SIDE

(TERMINAL NUMBERS 4 & 9)

POSITION "C" STATIONARY

TERMINAL SIDE

(TERMINAL NUMBERS 2 & 7)

COMMON TERMINALS (3 & 8)

TERMINAL LOCATIONS AS VIEWED FROM

BOTTOM OF SWITCH (CASE REMOVED FOR CLARITY)

CONTACT MADE IN OPPOSITE DIRECTION OF ROCKER TRAVEL

LIGHT TERMINAL LOCATION

IND/DEP IN "A"

(LED POLARITY NOTED)

LIGHT TERMINAL LOCATION

IND/DEP IN "C"

(LED POLARITY NOTED)

1.53

2X .50

SQ. LENSES

LENSES/LEGEND

LOCATIONS

1.730 MIN.

.870

MIN.

1.805

MAX.

.950

MAX.

REFERENCE PANEL

CUT-OUT

MOUNTING OPENING:

PANEL THICKNESS RANGE OF .025 - .105 A GASKET IS RECOMMENDED

PANEL THICKNESS RANGE OF .105 - .187 W/O GASKET

PANEL OPENING:

MIN.

TYP.

MAX.

WIDTH

.870

.937

.950

LENGTH 1.730 1.768

1.805
