background image
466 08/01
I In accordance with IEC 61860
I For transformers featuring high inductance
and low overall height
I ER11/5 cores are supplied in sets
Magnetic characteristics (per set)
Σl/A = 1,1 mm–1
le
= 14,1 mm
Ae
= 12,4 mm2
Ve
= 174 mm3
Approx. weight 0,85 g/set
Ungapped
Gapped
Material
AL value
nH
µe
Ordering code
T38
6400 + 40/– 30 %
5600
B65525-J-Y38
N49
800 + 30/– 20 %
715
B65525-J-R49
N87
1200 + 30/– 20 %
1050
B65525-J-R87
Material
AL value
nH
s
approx.
mm
µe
Ordering code
N87
160
± 3 %
0,08
140
B65525-J160-A87
B65525
Core
ER 11/5
