Preliminary Technical Data

ADL5533

Rev. PrC 5/07 | Page 3 of 9

SPECIFICATIONS

VCC = 5 V, T = 25°C, unless otherwise noted.

Table 1.

Parameter

Conditions

Min

Typ

Max

Unit

OVERALL FUNCTION

Frequency Range

1000

MHz

Gain vs. Frequency

± 50 MHz. Center Frequency = 190 MHz or 380 MHz

±0.25

Input Return Loss (S11)

50 MHz to 750 MHz

-10

Output Return Loss (S22)

50 MHz to 750 MHz

-10

FREQUENCY = 70 MHz

Gain

19.8

vs. Temperature

−40°C ≤ TA ≤ +85°C

±.25

Output 1 dB Compression Point

18.7

dBm

Output Third-Order Intercept

∆f = 1 MHz, Output Power (POUT) = 0 dBm (per tone)

37.3

dBm

Output Second Order Intercept

∆f = 1 MHz, Output Power (POUT) = 0 dBm (per tone)

TBD

dBm

Noise Figure

2.9

FREQUENCY = 380 MHz

Gain

18.6

vs. Temperature

−40°C ≤ TA ≤ +85°C

±.25

Output 1 dB Compression Point

18.8

dBm

Output Third-Order Intercept

∆f = 1 MHz, Output Power (POUT) = 0 dBm (per tone)

35.7

dBm

Output Second Order Intercept

∆f = 1 MHz, Output Power (POUT) = 0 dBm (per tone)

TBD

dBm

Noise Figure

3.1

FREQUENCY = 820 MHz

Gain

16.8

vs. Temperature

−40°C ≤ TA ≤ +85°C

±.25

Output 1 dB Compression Point

18.3

dBm

Output Third-Order Intercept

∆f = 1 MHz, Output Power (POUT) = 0 dBm (per tone)

34.5

dBm

Output Second Order Intercept

∆f = 1 MHz, Output Power (POUT) = 0 dBm (per tone)

TBD

dBm

Noise Figure

3.2

POWER INTERFACE

Pins RFOUT,Vcc

Supply Voltage

4.75

5.25

Supply Current

vs. Temperature

−40°C ≤ TA ≤ +85°C

Power Dissipation

VPOS = 5V

330
