Customer Specification

PART NO. 55152

Construction



Diameters (In)

1) Component 1

2 X 1 COND



a) Conductor

20 (7/28) AWG Tinned Copper

0.038

b) Insulation

0.010" Wall, Nom. FEP

0.058

(1) Color Code

Alpha Wire Color Code E

Cond

Color

Cond

Color

Cond

Color

1

BLACK

2

BROWN



2) Cable Assembly

2 Components Cabled



a) Twists:

8.0 Twists/foot (min)



b) Orientation:

Components to be arranged from INSIDE LAYER to

OUTSIDE LAYER



c) Core Wrap

PTFE(skived) Tape, 25% Overlap, Min.



3) Shield:

A/P/A Tape, 25% Overlap, Min.



a) Drain Wire

20 (7/28) AWG Tinned Copper



b) Braid

Tinned Copper,70% Coverage, Min.



4) Jacket

0.027" Wall, Nom.,FEP

0.204 (0.214 Max.)

a) Tint Color(s)

Natural Tan, Slate, Black, Yellow, Orange, Blue, Green, Red,

White

b) Ripcord

Para-Aramid fiber(Kevlar, Twaron or equal)



c) Marker Tape

ALPHA WIRE-*

XTRAGUARD(R) 5 - 20 AWG SHIELDED 150C (UL) CMP

OR AWM 20229 -- LLXXXXXX CSA CMP FT6

CE ROHS

* = Factory Code

[Note: Product may have c(UL) or CSA markings depending

upon plant of manufacture.]

Applicable Specifications
