24 / 30 page  TC7109/A DS21456C-page 24 © 2006 Microchip Technology Inc. 6.3 Package Dimensions Dimensions: inches (mm) 2.065 (52.45) 2.027 (51.49) .200 (5.08) .140 (3.56) .150 (3.81) .115 (2.92) .070 (1.78) .045 (1.14) .022 (0.56) .015 (0.38) .110 (2.79) .090 (2.29) .555 (14.10) .530 (13.46) .610 (15.49) .590 (14.99) .015 (0.38) .008 (0.20) .700 (17.78) .610 (15.50) .040 (1.02) .020 (0.51) 40-Pin PDIP (Wide) Pin1 3° Min. Dimensions: inches (mm) .015 (0.38) .008 (0.20) .620 (15.75) .590 (15.00) .700 (17.78) .620 (15.75) .540 (13.72) .510 (12.95) 2.070 (52.58) 2.030 (51.56) .210 (5.33) .170 (4.32) .020 (0.51) .016 (0.41) .110 (2.79) .090 (2.29) .065 (1.65) .045 (1.14) .200 (5.08) .125 (3.18) .098 (2.49) Max. .030 (0.76) Min. .060 (1.52) .020 (0.51) .150 (3.81) MIN. 40-Pin CERDIP (Wide) Pin 1 3° Min. |
|
