R

版本：202307A

1/6

双向晶闸管

TRIACS

CS0605N3A

主要参数

MAIN CHARACTERISTICS

封装 Package

序号

引线名称

Description

1

主电极 1

MT1

2

主电极 2

MT2

3

门极

G

IT(RMS)

6A

VDRM

800V

IGT（1,2,3）

6mA

用途

APPLICATIONS

⚫ 交流开关

⚫ AC switching

⚫ 相位控制

⚫ Phase control

产品特性

FEATURES

⚫ 玻璃钝化芯片，

高可靠性和一

致性

⚫ Glass-passivated mesa

chip for reliability and

uniform

⚫ 三象限可控硅，

触发电流的一

致性好

⚫ Uniform gate trigger

currents in three

quadrants

⚫ 环保 RoHS 产品

⚫ RoHS products

订货信息 ORDER MESSAGES

订货型号 Order codes

印

记 Marking

封

装 Package

有卤-编带

无卤-编带

CS0605N3A

DPAK

Halogen-Reel

Halogen-Free-Reel

CS0605N3A-R-A

CS0605N3A-R-AR

DPAK
