1 / 11 page

R

版本：202310F

1/11

双向晶闸管

TRIACS

CS810N3A

主要参数

MAIN CHARACTERISTICS

封装 Package

序号

引线名称

Description

1

主电极 1

MT1

2

主电极 2

MT2

3

门极

G

IT(RMS)

8A

VDRM

800V

IGT

10mA

用途

APPLICATIONS

⚫ 交流开关

⚫ AC switching

⚫ 相位控制

⚫ Phase control

产品特性

FEATURES

⚫ 玻璃钝化芯片，

高可靠性和一致

性

⚫ Glass-passivated mesa

chip for high reliability and

uniform

⚫ 低通态电流和高

浪涌电流能力

⚫ Low on-state voltage and

High ITSM

⚫ 环保 RoHS 产品

⚫ RoHS products

TO-220S

TO-220MF-K1

TO-220

TO-263

DPAK
