ADA4062-2/ADA4062-4
Rev. B | Page 13 of 20
FREQUENCY (Hz)
10
100
1000
110
100
1k
VSY = ±5V
Figure 47. Voltage Noise Density
TIME (1s/DIV)
VSY = ±5V
Figure 48. 0.1 Hz to 10 Hz Noise
–160
–140
–120
–100
–80
–60
–40
–20
0
100
1k
10k
100k
VSY = ±5V
VIN = 5V p-p
RL = 10kΩ
ADA4062-2 ONLY
FREQUENCY (Hz)
RL
100kΩ
1kΩ
Figure 49. Channel Separation vs. Frequency (ADA4062-2 Only)
FREQUENCY (Hz)
10
100
1000
110
100
1k
VSY = ±15V
Figure 50. Voltage Noise Density
TIME (1s/DIV)
VSY = ±15V
Figure 51. 0.1 Hz to 10 Hz Noise
–160
–140
–120
–100
–80
–60
–40
–20
0
100
1k
10k
100k
FREQUENCY (Hz)
VSY = ±15V
VIN = 10V p-p
RL = 10kΩ
ADA4062-2 ONLY
RL
100kΩ
1kΩ
Figure 52. Channel Separation vs. Frequency (ADA4062-2 Only)
