ADL5545
Data Sheet
Rev. B | Page 10 of 18
GENERAL
63
45
47
49
51
53
55
57
59
61
–40 –30 –20 –10 0
10 20 30 40 50 60 70 80 90 100 110
TEMPERATURE (°C)
5.00V
4.75V
5.25V
Figure 21. Supply Current vs. Temperature
40
35
30
25
20
15
10
5
0
GAIN (dB)
23.6
23.7
23.8
23.9
24.0
24.1
24.2
24.3
24.4
Figure 22. Gain Distribution at 900 MHz
30
25
20
15
10
5
0
P1dB (dBm)
17.6 17.7 17.8 17.9 18.0 18.1 18.2 18.3 18.4 18.5 18.6 18.7
Figure 23. P1dB Distribution at 900 MHz
70
50
52
54
56
58
60
62
64
66
68
1
19
17
15
13
11
9
7
5
3
POUT (dBm)
5.00V
4.75V
5.25V
Figure 24. Supply Current vs. POUT at 900 MHz
65
45
47
49
51
53
55
57
59
61
63
–8 –6 –4 –2
0
2
4
6
8
10 12 14 16 18 20 22
POUT (dBm)
+85°C
+105°C
–40°C
+25°C
Figure 25. Supply Current vs. POUT and Temperature at 900 MHz
25
20
15
10
5
0
31
32
33
34
35
36
37
38
39
40
41
OIP3 (dBm)
Figure 26. OIP3 Distribution at 900 MHz, POUT = −3 dBm per Tone
