STTH12010TV2 Scheda tecnica(PDF) 1 Page - STMicroelectronics |
|
|
|||||||||||||||||||||||||||||
STTH12010TV2 Scheda tecnica(HTML) 1 Page - STMicroelectronics |
|
|
1 / 8 page  March 2006 Rev 1 1/8 8 STTH12010TV Ultrafast recovery - high voltage diode Main product characteristics Features and benefits ■ Ultrafast, soft recovery ■ Very low conduction and switching losses ■ High frequency and/or high pulsed current operation ■ High reverse voltage capability ■ High junction temperature ■ Insulated package – Electrical insulation = 2500 VRMS Capacitance = 45 pF Description The compromise-free, high quality design of this diode has produced a device with low leakage current, regularly reproducible characteristics and intrinsic ruggedness. These characteristics make it ideal for heavy duty applications that demand long term reliability. These demanding applications include industrial power supplies, motor control, and similar industrial systems that require rectification and freewheeling. These diodes also fit into auxiliary functions such as snubber, bootstrap, and demagnetization applications. The improved performance in low leakage current, and therefore thermal runaway guard band, is an immediate advantage for reducing maintenance of the equipment Order codes IF(AV) 2 x 60 A VRRM 1000 V Tj 150° C VF (typ) 1.30 V trr (typ) 49 ns Part Number Marking STTH12010TV1 STTH12010TV1 STTH12010TV2 STTH12010TV2 K2 K1 A2 A1 K2 K1 A2 A1 A1 A1 A2 A2 K1 K1 K2 K2 ISOTOP STTH12010TV1 ISOTOP STTH12010TV2 www.st.com |
