1 / 5 page  ABRACON IS ISO9001-2015 CERTIFIED Ceramic Wirewound RF Inductor (AEC-Q200) AISC-Q0402 Series 1.27 x 0.76 x 0.61 mm RoHS/RoHS II Compliant MSL Level = 1 Request Samples Check Inventory REVISION Initial Release : 11/21/2023 5101 Hidden Creek Ln, Spicewood TX 78669 Phone: 512-371-6159 Fax: 512-351-8858 For terms and conditions of sales, please visit: www.abracon.com Part Number Inductance Code L (nH) Tolerance Q L/Q Test SRF DCR IDC Min 900MHz 1.7GHz Freq Min Max Max (MHz) (GHz) (Ω) (mA) 1N0 1.0 K 16 77 69 250 12.70 0.045 1360 1N9 1.9 C, D, J, K 16 68 82 250 11.30 0.070 1040 2N0 2.0 K 16 54 75 250 11.10 0.070 1040 2N2 2.2 J, K 19 59 100 250 10.80 0.070 960 2N4 2.4 K 15 51 68 250 10.50 0.070 790 2N7 2.7 J, K 16 42 61 250 10.40 0.120 640 3N3 3.3 K 19 65 87 250 7.00 0.066 840 3N6 3.6 J, K 19 45 71 250 6.80 0.066 840 3N9 3.9 J, K 19 50 75 250 5.80 0.066 840 4N3 4.3 J, K 18 47 71 250 6.00 0.091 700 4N7 4.7 J, K 18 48 68 250 4.70 0.130 640 5N1 5.1 G, J, K 20 56 82 250 4.80 0.083 800 5N6 5.6 J, K 20 54 81 250 4.80 0.083 760 6N2 6.2 J, K 20 52 76 250 4.80 0.083 760 6N8 6.8 G, J, K 20 63 78 250 4.80 0.083 680 7N5 7.5 G, J, K 22 60 88 250 4.80 0.104 680 8N2 8.2 J, K 22 57 84 250 4.40 0.104 680 8N7 8.7 J, K 18 54 73 250 4.10 0.200 480 9N0 9.0 J, K 22 62 78 250 4.16 0.104 680 9N5 9.5 J, K 18 54 69 250 4.00 0.200 480 10N 10 G, J, K 21 50 67 250 3.90 0.195 480 • PPAP ready and supported • TS16949 certified production lines • AEC-Q200 (grade 1) qualified • Ceramic base with high SRF • Excellent DCR and current carrying characteristics. • Ultra-compact inductors • Tight tolerance down to ±2% • Automotive applications • Bluetooth, W-LAN, Broadband Network • Impedance matching networks • Filtering for high frequency communication circuits • Video cameras, displays, and other electronic devices. Electrical Specifications Applications Features |
