High Q Ceramic Wirewound RF Inductor (AEC-Q200)

AISC-Q0603HQ Series

1.80 x 1.12 x 1.02 mm

RoHS/RoHS II Compliant

MSL Level = 1

Request Samples

Check Inventory

REVISION Initial Release :

11/21/2023

5101 Hidden Creek Ln, Spicewood TX 78669

Phone: 512-371-6159 Fax: 512-351-8858

For terms and conditions of sales, please visit:

www.abracon.com

Test Conditions:

Inductance, Q, SRF: HP4286/E4982A

DCR: Micro-Ohm meter (Gom-801G)/E4982A

IDC: Applied the current to coils, the temperature of coil increases ΔT15℃(Ta=25℃).

Operating Temperature: -40°C to +125°C

Components Storage Temperature: -40°C to +125°C

Tape and Reel packaging Temperature: 15~28°C; < 80% RH

AISC-Q0603HQ is AEC-Q200 Qualified

AISC-Q0603HQ Series is RoHS Compliant and Pb free

Part Number

Inductance Tolerance

Typ.

Quality

Factor @

250MHz

L/Q Test

Freq.

Typ.

Quality

Factor @

900MHz/

1.7GHz

Max. DC

Resistance

Max. Rated

Current

Typ. Self-resonant

Frequency

Units

nH

-

-

MHz

Ω

mA

MHz

Symbol

L

-

Q

Freq.

DCR

Ir

S.R.F

AISC-Q0603HQ-27N

27

G, J, K

44

250

74/84

0.150

780

2800

AISC-Q0603HQ-30N

30

G, J, K

49

250

82/82

0.130

920

2800

AISC-Q0603HQ-33N

33

G, J, K

45

250

76/80

0.170

680

2700

AISC-Q0603HQ-36N

36

G, J, K

44

250

69/64

0.225

720

2500

AISC-Q0603HQ-39N

39

G, J, K

48

250

78/74

0.190

680

2450

AISC-Q0603HQ-43N

43

G, J, K

45

250

83/76

0.170

810

2450

AISC-Q0603HQ-47N

47

G, J, K

47

200

77/72

0.240

680

2300

AISC-Q0603HQ-51N

51

G, J, K

49

200

73/62

0.280

660

2300

AISC-Q0603HQ-56N

56

G, J, K

50

200

74/56

0.300

610

2200

AISC-Q0603HQ-68N

68

G, J, K

46

200

73/49

0.330

600

2000

AISC-Q0603HQ-72N

72

G, J, K

34

150

50/38

0.350

580

1700

AISC-Q0603HQ-75N

75

G, J, K

46

150

71/-

0.52

500

1900

AISC-Q0603HQ-82N

82

G, J, K

45

150

62/-

0.46

510

1800

AISC-Q0603HQ-91N

91

G, J, K

45

150

64/-

0.58

440

1650

AISC-Q0603HQ-R10

100

G, J, K

49

150

69/-

0.54

470

1700

AISC-Q0603HQ-R11

110

G, J, K

47

150

63/-

0.58

440

1600

AISC-Q0603HQ-R12

120

G, J, K

47

150

61/-

0.72

420

1550

AISC-Q0603HQ-R15

150

G, J, K

47

150

57/-

0.82

390

1350

AISC-Q0603HQ-R18

180

G, J, K

48

100

50/-

1.50

310

1300

AISC-Q0603HQ-R20

200

G, J, K

47

100

47/-

2.00

280

1250

AISC-Q0603HQ-R21

210

G, J, K

48

100

45/-

2.00

280

1200

AISC-Q0603HQ-R22

220

G, J, K

47

100

41/-

2.00

280

1100

AISC-Q0603HQ-R25

250

G, J, K

45

100

-/-

3.00

240

1050

AISC-Q0603HQ-R27

270

G, J, K

46

100

-/-

2.25

260

1050

AISC-Q0603HQ-R30

300

G, J, K

47

100

-/-

2.80

220

990

AISC-Q0603HQ-R33

330

G, J, K

46

100

-/-

3.60

180

930

AISC-Q0603HQ-R36

360

G, J, K

47

100

-/-

4.00

170

930

AISC-Q0603HQ-R39

390

G, J, K

47

100

-/-

4.00

170

880

Electrical Specifications (Cont’d)
