1 / 6 page  December 2006 Rev 1 1/6 6 STTH8006 Turbo 2 ultrafast high voltage rectifier Main product characteristics Features and benefits ■ Ultrafast switching ■ Low reverse current ■ Low thermal resistance ■ Reduces switching and conduction losses Description The STTH8006, which is using ST Turbo 2 600V technology, is specially suited for use in switching power supplies, and industrial applications, as rectification and discontinuous mode PFC boost diode. Thanks to its low VF characteristics, this device exhibits high performances in free- wheeling applications. Order Code IF(AV) 80 A VRRM 600 V Tj 175 °C VF (typ) 1.02 V trr (max) 70 ns Part number Marking STTH8006W STTH8006W K A DO-247 STTH8006W Table 1. Absolute ratings (limiting values, at Tamb = 25 °C, unless otherwise specified) Symbol Parameter Value Unit VRRM Repetitive peak reverse voltage 600 V IF(RMS) RMS forward voltage 113 A IF(AV) Average forward current Tc = 75 °C δ = 0.5 80 A IFSM Surge non repetitive forward current tp = 10 ms sinusoidal 500 A Tstg Storage temperature range -65 to + 175 °C Tj Maximum operating junction temperature 175 °C www.st.com |
