E5CS-R1KJX Scheda tecnica(PDF) 5 Page - Omron Electronics LLC |
|
|
|||||||||||||||||||||||||||||
E5CS-R1KJX Scheda tecnica(HTML) 5 Page - Omron Electronics LLC |
|
|
5 / 12 page  E5CS-X E5CS-X 5 Nomenclature LED Deviation Indicators n lights when the present tempera- ture is higher than the set tempera- ture, and o lights when it is lower. The j indicator lights in green if the deviation is within ±1% of the full scale. Mode Indicator SP lights while the set temperature is displayed on the main display, and AL lights while an alarm value is being displayed. Protection Key When program protection is selected using the internal DIP switch, the upward and downward setting keys are locked. However, authorized personnel may change values using the upward and downward setting keys by holding down hidden protection key. Main Display Sequentially displays the present temperature, set temperature, and an alarm value (in that order) each time the temperature indication switching ( ) key is pressed. Control Output Indicator Lights while the control output is be- ing produced. Alarm Output Operation Indicator Lights when the alarm output relay is energized. Upward Setting Key When pressed, increases the set temperature/alarm value. Successively increases the value when held down. Downward Setting Key When pressed, decreases the set temperature/alarm value. Successively decreases the value when held down. Temperature Indication Switching Key Each time pressed, changes the value dis- played on the main display in the following sequence. |
|
|
