DC and AC parameters

M95M01-R

30/39

Table 11.

DC characteristics(1)

The information contained in this table is preliminary data. It is subject to change without previous notice.

Symbol

Parameter

Test condition

Min

Max

Unit

ILI

Input leakage current

VIN = VSS or VCC

± 2

µA

ILO

Output leakage current

S = VCC, VOUT = VSS or VCC

± 2

µA

ICC

Supply current (Read)

C = 0.1VCC/0.9VCC at 2 MHz,

VCC = 1.8 V, Q = open

1.5

C = 0.1VCC/0.9VCC at 5 MHz,

VCC = 2.5 V, Q = open

4mA

C = 0.1VCC/0.9VCC at 5 MHz,

VCC = 5 V, Q = open

5mA

ICC0

(2)

Characterized value, not tested in production.

Supply current (Write)

During tW, S = VCC,

1.8 V

≤ V

CC < 2.5 V

3mA

During tW, S = VCC,

2.5 V

≤ V

CC ≤ 5.5 V

5mA

ICC1

Supply current (Standby

Power mode)

S = VCC, VIN = VSS or VCC,

1.8 V

≤ V

CC < 2.5 V

3µA

S = VCC, VIN = VSS or VCC,

2.5 V

≤ V

CC ≤ 5.5 V

5µA

VIL

Input low voltage

1.8 V

≤ V

CC < 2.5 V

–0.45

0.25 VCC

2.5 V

≤ V

CC ≤ 5.5 V

–0.45

0.3 VCC

VIH

Input high voltage

1.8 V

≤ V

CC < 2.5 V

0.75 VCC

VCC+1

2.5 V

≤ V

CC ≤ 5.5 V

0.7 VCC

VCC+1

VOL

Output low voltage

IOL = 0.15 mA, VCC = 1.8 V

0.3

VCC = 2.5 V, IOL = 1.5 mA or

VCC = 5 V, IOL = 2 mA

0.4

VOH

Output high voltage

IOH = –0.1 mA, VCC = 1.8 V

0.8 VCC

VCC = 2.5 V, IOH = –0.4 mA or

VCC = 5 V, IOH = –2 mA
