background image
www.ti.com
Time(400ns/div)
V
=2.7V
IntV
=2.5V
FromCode:7FFFh
ToCode:8000h
Glitch:0.08nV-s
DD
REF
Time(400ns/div)
V
=2.7V
IntV
=2.5V
FromCode:8000h
ToCode:7FFFh
Glitch:0.16nV-s
MeasuredWorstCase
DD
REF
Time(400ns/div)
V
=2.7V
IntV
=2.5V
FromCode:8000h
ToCode:8010h
Glitch:0.04nV-s
DD
REF
Time(400ns/div)
V
=2.7V
IntV
=2.5V
FromCode:8010h
ToCode:8000h
Glitch:0.12nV-s
DD
REF
Time(400ns/div)
V
=2.7V
IntV
=2.5V
FromCode:8000h
ToCode:80FFh
Glitch:NotDetected
TheoreticalWorstCase
DD
REF
Time(400ns/div)
V
=2.7V
IntV
=2.5V
FromCode:80FFh
ToCode:8000h
Glitch:NotDetected
TheoreticalWorstCase
DD
REF
DAC8564
SBAS403A – JUNE 2007 – REVISED NOVEMBER 2007
TYPICAL CHARACTERISTICS: DAC at VDD = 2.7V (continued)
At TA = +25°C, internal reference used, and DAC output not loaded, all DAC codes in straight binary data format, unless
otherwise noted
GLITCH ENERGY:
GLITCH ENERGY:
2.7V, 1LSB STEP, RISING EDGE
2.7V, 1LSB STEP, FALLING EDGE
Figure 84.
Figure 85.
GLITCH ENERGY:
GLITCH ENERGY:
2.7V, 16LSB STEP, RISING EDGE
2.7V, 16LSB STEP, FALLING EDGE
Figure 86.
Figure 87.
GLITCH ENERGY:
GLITCH ENERGY:
2.7V, 256LSB STEP, RISING EDGE
2.7V, 256LSB STEP, FALLING EDGE
Figure 88.
Figure 89.
Copyright © 2007, Texas Instruments Incorporated
Submit Documentation Feedback
23
Product Folder Link(s): DAC8564
