RPM7237-R series

Photo Link Module

Rev.B

1/6

IR Receiver Module

RPM7237-R series

RPM7237-R series are remote control receiver module. Small-sized, light-weight, and low voltage operated (from 2.7V)

modules have been achieved by using resin mold.

Center frequency

36.7kHz

Applications

All household electric appliances such as TV, DVD, air conditioner and audio equipment.

Features

1) Low voltage operation. (VCC=2.7 to 3.6V)

2) Low current consumption. (ICC=0.3mA, VCC=3V)

3) Superior anti VCC noise characteristics.

4) 5 types of holders available to each set.

RPM7237-R series

Sub carrier

frequency

SIDE VIEW

TOP VIEW

RSIP-A3 (H9)

12.0mm

RPM7237-H9R

∗Under development

RSIP-A3 (H8)

7.2mm

RPM7237-H8R

RSIP-A3 (H13)

15.0mm

∗RPM7237-H13R

RSIP-A3 (H5)

9.6mm

RPM7237-H5R

RSIP-A3 (H4)

15.9mm

RPM7237-H4R

Height to lens

36.7kHz

Absolute maximum ratings (Ta = 25

°C)

Parameter

Symbol

Limits

Unit

VCC

6.3

−30 to +100

2.0

V

Output current

Tstg

IO

°C

mA

Supply Voltage

Storage temperature

−10 to +75

Topr

°C

Operating temperature voltage

Recommended operating conditions (Ta = 25

°C)

Parameter

Symbol

Min.

Typ.

Max.

Unit

Supply voltage

VCC

3.0

V

2.7

3.6

Codice articolo simile - RPM7237-R

Produttore elettronici	Il numero della parte	Scheda tecnica	Spiegazioni elettronici
Rohm	RPM7237-H13	166Kb / 7P	IR Receiver Module
	RPM7237-H13	223Kb / 7P	IR Receiver Module
	RPM7237-H4	166Kb / 7P	IR Receiver Module
	RPM7237-H4	223Kb / 7P	IR Receiver Module
	RPM7237-H5	166Kb / 7P	IR Receiver Module

More results

Descrizione simile - RPM7237-R

Produttore elettronici	Il numero della parte	Scheda tecnica	Spiegazioni elettronici
Rohm	RPM7200	166Kb / 7P	IR Receiver Module
	RPM7100	175Kb / 8P	IR Receiver Module
	RPM7236	140Kb / 7P	IR Receiver Module
	RPM7137	213Kb / 8P	IR Receiver Module
	RPM7138	198Kb / 8P	IR Receiver Module
	RPM7138-R	120Kb / 8P	IR Receiver Module
	RPM7140-R	118Kb / 8P	IR Receiver Module
	RPM7157-R	156Kb / 8P	IR Receiver Module
	RPM7236-R	120Kb / 7P	IR Receiver Module
	RPM6900	108Kb / 8P	IR Receiver Module

More results

RPM7237-R Scheda tecnica(PDF) 1 Page - Rohm
