RPM7240-R series

Photo Link Module

Rev.B

1/6

IR Receiver Module

RPM7240-R series

RPM7240-R series are remote control receiver module. Small-sized, light-weight, and low voltage operated (from 2.7V)

modules have been achieved by using resin mold.

Center frequency

40.0kHz

Applications

All household electric appliances such as TV, DVD, air conditioner and audio equipment.

Features

1) Low voltage operation. (VCC=2.7 to 3.6V)

2) Low current consumption. (ICC=0.3mA, VCC=3V)

3) Superior anti VCC noise characteristics.

4) 5 types of holders available to each set.

RPM7240-R series

SIDE VIEW

TOP VIEW

RSIP-A3 (H9)

12.0mm

RPM7240-H9R

RSIP-A3 (H8)

7.2mm

RPM7240-H8R

RSIP-A3 (H13)

15.0mm

RPM7240-H13R

RSIP-A3 (H5)

9.6mm

RPM7240-H5R

RSIP-A3 (H4)

15.9mm

RPM7240-H4R

Height to lens

Products No.

Absolute maximum ratings (Ta = 25

°C)

Parameter

Symbol

Limits

Unit

VCC

6.3

−30 to +100

2.0

V

Output current

Tstg

IO

°C

mA

Supply Voltage

Storage temperature

−10 to +75

Topr

°C

Operating temperature voltage

Recommended operating conditions (Ta = 25

°C)

Parameter

Symbol

Min.

Typ.

Max.

Unit

Supply voltage

VCC

3.0

V

2.7

3.6
