PS21661-RZ/-FR

Intellimod™ Module

Single-In-Line Intelligent Power Module

3 Amperes/600 Volts

Powerex, Inc., 200 E. Hillis Street, Youngwood, Pennsylvania 15697-1800 (724) 925-7272

Electrical and Mechanical Characteristics, Tj = 25°C unless otherwise specified

Characteristics

Symbol

Test Conditions

Min.

Typ.

Max.

Units

IGBT Inverter Sector

Collector Cutoff Current

ICES

VCE = VCES, Tj = 25°C—

—

1.0

VCE = VCES, Tj = 125°C—

—

Diode Forward Voltage

VEC

Tj = 25°C, -IC = 3A, VIN = 0V

—

1.55

2.00

Volts

Collector-Emitter Saturation Voltage

VCE(sat)

IC = 3A, Tj = 25°C, VD = VDB = 15V, VIN = 5V

—

1.60

2.15

Volts

IC = 3A, Tj = 125°C, VD = VDB = 15V, VIN = 5V

—

1.70

2.30

Volts

Inductive Load Switching Times

ton

0.50

0.85

1.25

µS

trr

VCC = 300V, VD = VDB = 15V,

—

0.20

—

µS

tC(on)

IC = 3A, Tj = 125°C, VIN = 0 ⇔ 5V,

—

0.35

0.55

µS

toff

Inductive Load (Upper-Lower Arm)

—

1.00

1.50

µS

tC(off)

—

0.55

1.10

µS

Thermal Characteristics

Characteristic

Symbol

Condition

Min.

Typ.

Max.

Units

Junction to Fin

Rth(j-f)Q

IGBT Part (Per 1/6 Module)

—

9.0

°C/Watt

Thermal Resistance

Rth(j-f)D

FWDi Part (Per 1/6 Module)

—

9.0

°C/Watt

Recommended Conditions for Use

Characteristic

Symbol

Condition

Min.

Typ.

Value

Units

Supply Voltage

VCC

Applied between P-N Terminals

300

400

Volts

Control Supply Voltage

Applied between VN1-VNC

13.5

15.0

16.5

Volts

VDB

Applied between

13.0

15.0

18.5

Volts

VUFB-U(VUFS), VVFB-V(VVFS), VWFB-W(VWFS)

Control Supply Variation

∆VD, ∆VDB

-1

—

µs

PWM Input Frequency

fPWM

Tf ≤ 100°C, Tj ≤ 125°C—

—

kHz

Allowable RMS Current*

VCC = 300V, VD = 15V, fc = 15kHz,

—

Arms

PF = 0.8 Sinusoidal, Tj ≤ 125°C, Tf ≤ 100°C

VNC Terminal Voltage

VNC

Applied between VNC-N (Include Surge Voltage)

-5

—

Volts

Minimum Input Pulse Width**

PWIN

ON/OFF

0.3

—

µS

Arm Shoot-through Blocking Time

tDEAD

For Each Input Signal

1.5

—

µS

* The allowable RMS current value depends on the actual application conditions.

**There might be no output when the input signal width is less than PWIN.
