Item

Communications

power supply voltage

Communications power

current consumption

Noise immunity

Vibration resistance

Shock resistance

Dielectric strength

Insulation resistance

Ambient operating

temperature

Ambient humidity

Ambient environment

Ambient storage

temperature

Mounting method

Screw tightening

torque

Weight

11 to 25 VDC (Supplied from the communications

connector.)

395 mA

Conforms to IEC61000-4-4, 2 kV (power line)

10 to 55 Hz, 0.7-mm double amplitude

100 m/s2

500 VAC (between isolated circuits)

20 M

Ω min.

–10 to 55

°C

Operating: 25% to 85% (with no condensation)

Must be free from corrosive gases.

–25 to 65

°C

35-mm DIN Track mounting

0.26 to 0.3 N•m

M3 (screw terminals): 0.3 to 0.5 N•m

260 g max.

Model number

DRT2-ROS16

Expansion Systems

XWT-series Expansion I/O Units are easily added. This allows free expansion of contacts.

Separate wiring of I/O power supply to Expansion I/O Units is required. Note: Refer to the manual for details on the XWT Series.

Addition of Expansion Units

125
