TPS Series

Low ESR

11) –Dry pack option (see How to order) is recommended for reduction of stress during solder-

ing. Dry pack parts should be treated as MSL 3.

For AEC-Q200 availability, please contact AVX.

Moisture Sensitivity Level (MSL) is defined according to J-STD-020

All technical data relates to an ambient temperature of +25°C. Capacitance and

DF are measured at 120Hz, 0.5V RMS with a maximum DC bias of 2.2 volts.

DCL ismeasured at rated voltage after 5 minutes.

The EIA & CECC standards for low ESR Solid Tantalum Capacitors allow an ESR movement

to 1.25 times catalogue limit post mounting.

For typical weight and composition see page 269.

NOTE: AVX reserves the right to supply higher voltage ratings or tighter tolerance part

in the same case size, to the same reliability standards.

RATINGS & PART NUMBER REFERENCE

Rated

Rated

Category

Category

DCL

DF

ESR

100kHz RMS Current (A)

AVX

Case

Capacitance

Voltage

Temperature Voltage

Temperature

Max.

Max.

Max.

MSL

Part No.

Size

(μF)

(V)

(ºC)

(V)

(ºC)

(μA)

(%)

@ 100kHz

25ºC

85ºC

125ºC

(mΩ)

TPSE476*035#0200

E

47

35

85

23

125

16.5

6

200

0.908

0.817

0.363

1

1)

TPSE476*035#0250

E

47

35

85

23

125

16.5

6

250

0.812

0.731

0.325

1

1)

TPSV476*035#0150

V

47

35

85

23

125

16.5

6

150

1.291

1.162

0.516

1

1)

TPSV476*035#0200

V

47

35

85

23

125

16.5

6

200

1.118

1.006

0.447

1

1)

TPSV686*035#0150

V

68

35

85

23

125

23.8

6

150

1.291

1.162

0.516

1

1)

TPSV686*035#0200

V

68

35

85

23

125

23.8

6

200

1.118

1.006

0.447

1

1)

50 Volt @ 85°C

TPSA154*050#9000

A

0.15

50

85

33

125

0.5

4

9000

0.091

0.082

0.037

1

TPSA224*050#7000

A

0.22

50

85

33

125

0.5

4

7000

0.104

0.093

0.041

1

TPSA334*050#7000

A

0.33

50

85

33

125

0.5

4

7000

0.104

0.093

0.041

1

TPSA474*050#6500

A

0.47

50

85

33

125

0.5

4

6500

0.107

0.097

0.043

1

TPSB474*050#6000

B

0.47

50

85

33

125

0.5

4

6000

0.119

0.107

0.048

1

TPSC474*050#2300

C

0.47

50

85

33

125

0.5

4

2300

0.219

0.197

0.087

1

TPSB684*050#4000

B

0.68

50

85

33

125

0.5

4

4000

0.146

0.131

0.058

1

TPSB105*050#3000

B

1

50

85

33

125

0.5

6

3000

0.168

0.151

0.067

1

TPSC105*050#2500

C

1

50

85

33

125

0.5

4

2500

0.210

0.189

0.084

1

TPSC155*050#1500

C

1.5

50

85

33

125

0.8

6

1500

0.271

0.244

0.108

1

TPSC155*050#2000

C

1.5

50

85

33

125

0.8

6

2000

0.235

0.211

0.094

1

TPSC225*050#1500

C

2.2

50

85

33

125

1.1

8

1500

0.271

0.244

0.108

1

TPSD225*050#1200

D

2.2

50

85

33

125

1.1

6

1200

0.354

0.318

0.141

1

TPSC335*050#1000

C

3.3

50

85

33

125

1.6

6

1000

0.332

0.298

0.133

1

TPSD335*050#0800

D

3.3

50

85

33

125

1.7

6

800

0.433

0.390

0.173

1

TPSC475*050#0800

C

4.7

50

85

33

125

2.4

6

800

0.371

0.334

0.148

1

TPSD475*050#0250

D

4.7

50

85

33

125

2.4

6

250

0.775

0.697

0.310

1

TPSD475*050#0300

D

4.7

50

85

33

125

2.4

6

300

0.707

0.636

0.283

1

TPSD475*050#0500

D

4.7

50

85

33

125

2.4

6

500

0.548

0.493

0.219

1

TPSD475*050#0700

D

4.7

50

85

33

125

2.4

6

700

0.463

0.417

0.185

1

TPSX475*050#0500V

X

4.7

50

85

33

125

2.4

6

500

0.447

0.402

0.179

3

TPSD685*050#0200

D

6.8

50

85

33

125

3.4

6

200

0.866

0.779

0.346

1

TPSD685*050#0300

D

6.8

50

85

33

125

3.4

6

300

0.707

0.636

0.283

1

TPSD685*050#0500

D

6.8

50

85

33

125

3.4

6

500

0.548

0.493

0.219

1

TPSD685*050#0600

D

6.8

50

85

33

125

3.4

6

600

0.500

0.450

0.200

1

TPSD106*050#0500

D

10

50

85

33

125

5

6

500

0.548

0.493

0.219

1

TPSE106*050#0250

E

10

50

85

33

125

5

6

250

0.812

0.731

0.325

1

1)

TPSE106*050#0300

E

10

50

85

33

125

5

6

300

0.742

0.667

0.297

1

1)

TPSE106*050#0400

E

10

50

85

33

125

5

6

400

0.642

0.578

0.257

1

1)

TPSE106*050#0500

E

10

50

85

33

125

5

6

500

0.574

0.517

0.230

1

1)

TPSE156*050#0250

E

15

50

85

33

125

7.5

6

250

0.812

0.731

0.325

1

1)

TPSV156*050#0250

V

15

50

85

33

125

7.5

6

250

1.000

0.900

0.400

1

1)
