CW2012A Series – 0805 Chip Inductors

Features

n

Miniature size

n

High self-resonant frequency

n

High current

n

Low DCR

n

High Q

n

AEC-Q200 compliant

n

RoHS compliant* and halogen free**

Applications

n

Radio transmitters

n

RF amplifiers

n

Tuning applications

n

High frequency applications

n

Automotive systems

Electrical Specifications

Bourns

Part No.

Inductance

Q

L @ Test

Frequency

(Hz)

Q @ Test

Frequency

(MHz)

SRF (MHz)

DCR (Ω)

Rated Current

(mA)

L (nH)

Tol.

Min.

Min.

Max.

Max.

CW2012A-2N0_

2.0

±0.2 nH,

±0.3 nH

70

0.1 V / 250 M

1500

8000

0.03

800

CW2012A-3N9_

3.9

70

5750

0.04

CW2012A-4N7_

4.7

70

5750

0.04

CW2012A-6N8_

6.8

±5 %,

± 10 %

70

5500

0.06

CW2012A-7N5_

7.5

70

1000

4500

0.06

CW2012A-8N2_

8.2

70

4700

0.06

CW2012A-10N_

10

70

4200

0.08

600

CW2012A-12N_

12

80

4000

0.08

CW2012A-15N_

15

80

3400

0.10

CW2012A-18N_

18

80

3300

0.10

CW2012A-22N_

22

60

500

2600

0.12

CW2012A-24N_

24

60

2000

0.12

CW2012A-27N_

27

60

2500

0.12

CW2012A-33N_

33

60

2050

0.13

CW2012A-36N_

36

65

1700

0.13

CW2012A-39N_

39

65

2000

0.15

CW2012A-43N_

43

65

0.1 V / 200 M

1650

0.15

CW2012A-47N_

47

65

1650

0.17

CW2012A-56N_

56

65

1550

0.19

CW2012A-68N_

68

60

1450

0.22

500

CW2012A-82N_

82

55

0.1 V / 150 M

1300

0.40

400

CW2012A-R10_

100

55

1200

0.52

CW2012A-R11_

110

55

1200

0.52

CW2012A-R12_

120

50

250

1100

0.55

CW2012A-R15_

150

50

920

0.73

CW2012A-R18_

180

50

0.1 V / 100 M

870

0.88

CW2012A-R22_

220

50

850

1.18

340

CW2012A-R24_

240

48

690

1.20

330

CW2012A-R27_

270

48

650

1.36

310

CW2012A-R33_

330

40

600

1.40

300

CW2012A-R39_

390

25

560

1.50

290

CW2012A-R47_

470

25

0.1 V / 50 M

100

375

1.76

250

CW2012A-R56_

560

23

0.1 V / 25 M

340

1.90

210

CW2012A-R62_

620

23

220

2.00

105

CW2012A-R68_

680

23

200

2.15

200

CW2012A-R75_

750

20

200

2.25

185

CW2012A-R82_

820

20

200

2.50

170

CW2012A-1R0_

1000

15

50

100

2.60

170

Note:

Underscore indicates Inductance Tolerance Code:

CW2012A-2N0_ ~ CW2012A-4N7_: B = ±0.2 nH, D = ±0.3 nH

CW2012A-6N8_ ~ CW2012A-1R0_: J = ±5 %, K = ±10 %
