ADL5541

Rev. 0 | Page 3 of 12

SPECIFICATIONS

VPOS = 5 V and TA = 25°C, unless otherwise noted.

Table 1.

Parameter

Conditions

Min

Typ

Max

Unit

OVERALL FUNCTION

Frequency Range

6000

MHz

Gain (S21)

900 MHz

15.2

Input Return Loss (S11)

Frequency 500 MHz to 5 GHz

−12

Output Return Loss (S22)

Frequency 500 MHz to 5 GHz

−10

Reverse Isolation (S12)

−19

FREQUENCY = 100 MHz

Gain

15.7

Output 1 dB Compression Point

dBm

Output Third-Order Intercept

Δf = 1 MHz, output power (POUT) = 0 dBm per tone

dBm

Noise Figure

3.5

FREQUENCY = 500 MHz

Gain

14.7

15.1

15.5

vs. Frequency

±50 MHz

±0.15

vs. Temperature

−40°C ≤ TA ≤ +85°C

±0.1

vs. Supply

4.75 V to 5.25 V

±0.01

Output 1 dB Compression Point

19.9

dBm

Output Third-Order Intercept

Δf = 1 MHz, output power (POUT) = 3 dBm per tone

dBm

Noise Figure

3.5

3.7

FREQUENCY = 900 MHz

Gain

14.9

15.2

15.4

vs. Frequency

±50 MHz

±0.03

vs. Temperature

−40°C ≤ TA ≤ +85°C

±0.15

vs. Supply

4.75 V to 5.25 V

±0.01

Output 1 dB Compression Point

19.7

dBm

Output Third-Order Intercept

Δf = 1 MHz, output power (POUT) = 0 dBm per tone

40.8

dBm

Noise Figure

3.5

3.7

FREQUENCY = 2000 MHz

Gain

13.9

14.7

15.4

vs. Frequency

±50 MHz

±0.03

vs. Temperature

−40°C ≤ TA ≤ +85°C

±0.17

vs. Supply

4.75 V to 5.25 V

±0.01

Output 1 dB Compression Point

16.3

dBm

Output Third-Order Intercept

Δf = 1 MHz, output power (POUT) = 0 dBm per tone

39.2

dBm

Noise Figure

3.8

4.0

FREQUENCY = 2400 MHz

Gain

13.9

14.5

15.1

vs. Frequency

±50 MHz

±0.03

vs. Temperature

−40°C ≤ TA ≤ +85°C

±0.19

vs. Supply

4.75 V to 5.25 V

±0.02

Output 1 dB Compression Point

14.9

dBm

Output Third-Order Intercept

Δf = 1 MHz, output power (POUT) = 0 dBm per tone

38.6

dBm

Noise Figure

4.0

4.2
