CC1070

SWRS043A

Page 52 of 54

25 Package Marking

When contacting technical support with a chip-related question, please state the entire marking

information as stated below (this is for RGW package).

o – pin one symbolization

TI – TI letters

YM – Year Month Date Code

SLLLL – Assembly Lot Code

G4 – fixed code

25.1 Soldering Information

The recommendation for lead-free reflow in IPC/JEDEC J-STD-020 should be followed.

25.2 Tray Specification

QFN 5x5 mm standard shipping tray.

Tray Specification

Package

Tray Width

Tray Height

Tray Length

Units per Tray

QFN 20 (RSQ)

135.9 mm

7.62 mm

315 mm

490

25.3 Carrier Tape and Reel Specification

Carrier tape and reel is in accordance with EIA Specification 481.

Tape and Reel Specification

Package

Tape Width

Component

Pitch

Hole

Pitch

Reel

Diameter

Units per Reel

QFN 20 (RSQR)

12 mm

8 mm

4 mm

13”

5000

CC1070

TI YMS

LLLL G4
