Burgess switches

www.burgess-switch.com

burgess-switch@johnsonelectric.om

V4L

Basic type

V4L

Type of sealing

No symbol, unsealed

S

Sealed IP6K7

Terminals

No symbol, pre-wired 500 mm with cable FLRY 0.5 mm2 and cable box (V4LS only)

T7

Solder

2.95 T 0.5 T 3.55 long

Circuit

No symbol, change over

Actuators

No symbol, without lever

A1

Plain lever

20.0 mm, fitted at the end opposite to plunger

A2

Plain lever

30.0 mm, fitted at the end opposite to plunger

F

Special lever F type

20.0 mm, fitted at the end opposite to plunger

Contact Material

No symbol, Ag

X

Gold alloy on silver palladium crosspoint (AUX)

Other contact materials on special request

Approvals

No symbol, without approval

UL

UL and CSA approval

EN

ENEC approval only

UN

UL, CSA and ENEC approval

Special Features

/

□□□□

Burgess specialise in customer specific solutions.

Additional product variants are available or can be provided.

If your requirements cannot be satisfied from the options listed,

please contact us.

Ordering Reference

Example: V4L

S

T7

A1

X

UL
