MBR30x5CT, MBRF30x5CT, MBRB30x5CT

www.vishay.com

Vishay General Semiconductor

Revision: 11-Jun-13

2

Document Number: 88677

Notes

(1) Pulse test: 300 μs pulse width, 1 % duty cycle

(2) Pulse test: Pulse width

 40 ms

Note

(1) AEC-Q101 qualified

ELECTRICAL CHARACTERISTICS (TC = 25 °C unless otherwise noted)

PARAMETER

SYMBOL

TEST CONDITIONS

VALUE

UNIT

Maximum instantaneous forward voltage per diode

VF (1)

IF = 20 A

TC = 125°C

0.60

V

IF = 30 A

TC = 25°C

0.76

IF = 30 A

TC = 125°C

0.72

Maximum instantaneous reverse current at DC blocking voltage

per diode

IR (1)

Rated VR

TJ = 25 °C

1.0

mA

TJ = 125 °C

60

THERMAL CHARACTERISTICS (TC = 25 °C unless otherwise noted)

PARAMETER

SYMBOL

MBR

MBRF

MBRB

UNIT

Typical thermal resistance per diode

RJC

1.5

4.5

1.5

°C/W

ORDERING INFORMATION (Example)

PACKAGE

PREFERRED P/N

UNIT WEIGHT (g)

PACKAGE CODE

BASE QUANTITY

DELIVERY MODE

TO-220AB

MBR3045CT-E3/45

1.85

45

50/tube

Tube

ITO-220AB

MBRF3045CT-E3/45

1.99

45

50/tube

Tube

TO-263AB

MBRB3045CT-E3/45

1.35

45

50/tube

Tube

TO-263AB

MBRB3045CT-E3/81

1.35

81

800/reel

Tape and reel

TO-220AB

MBR3045CTHE3/45 (1)

1.85

45

50/tube

Tube

ITO-220AB

MBRF3045CTHE3/45 (1)

1.99

45

50/tube

Tube

TO-263AB

MBRB3045CTHE3/45 (1)

1.35

45

50/tube

Tube

TO-263AB

MBRB3045CTHE3/81 (1)

1.35

81

800/reel

Tape and reel
