IP113A LF

Preliminary Data Sheet

10/22

April 9, 2007

IP113A LF-DS-R08

PIN Description (continued)

Pin no.

Label

Type

Description

EEPROM interface

45, 46

SDA, SCL

IPH, O EEPROM interface

37, 12, 46

A[2:0]

IPL

PHY address

IP113A LF uses A[2:0] as EEPROM address to read

EPROM.

Pin no.

Label

Type

Description

Misc.

RESETB

Reset

It is low active.

41, 40

OSCI, X2

I, O

Crystal pins

OSCI and X2 are connected to a 25Mhz crystal.

If a 25MHz oscillator is used, OSCI is connected to the

oscillator’s output and X2 should be left open.

26, 27

TSM, TSE

IPL

Scan pins

These two pins should be left open or connected to ground

for normal operation.

Pin no.

Label

Type

Description

Power

1,7,11

AVCC

2.5V Analog Power

19,39,44

VCC

2.5V Digital Power

VCC_IO

3.3V or 2.5V Digital Power

GND_IO

I/O Ground

4,10,20,

42,43

GND

Ground
