DFR0646-G, DFR0646-R

Introduction

This 8-digit 7 segment display module has two colors to choose: red and green. It

supports 16-level brigthness adjustment and can be drived via two normal I/O ports.

The display features 4 different slave addresses, standard IIC pins, compatible with

Gravity interface, and free from MCU scanning.

Specification

•

Power Supply: DC 5V

•

Operating Current: <130mA

•

IIC Bus Interface

•

Provides 16-level Brightness Adjustment

•

16 x 8 bits RAM for storing displayed data
