background image
PACKAGE MECHANICAL DATA
TO-220AB F5 OPTION
REF.
DIMENSIONS
Millimeters
Inches
Min.
Max.
Min.
Max.
A
15.20
15.90
0.598
0.625
a1
24.16
26.90
0.951
1.059
a3
1.65
2.41
0.064
0.094
B
10.00
10.40
0.393
0.409
b1
0.61
0.88
0.024
0.034
b2
1.23
1.32
0.048
0.051
C
4.40
4.60
0.173
0.181
c1
0.49
0.70
0.019
0.027
c2
2.40
2.72
0.094
0.107
e
2.40
2.70
0.094
0.106
F
6.20
6.60
0.244
0.259
I
3.75
3.85
0.147
0.151
L
2.65
2.95
0.104
0.116
I2
1.14
1.70
0.044
0.066
l3
1.14
1.70
0.044
0.066
l4
15.80
16.80
0.622
0.661
16.40 typ.
0.645 typ.
M1
2.92
3.30
0.114
0.129
R1
1.40 typ.
0.055 typ.
R2
1.40 typ.
0.055 typ.
c2
B
a1
C
b2
l2
c2
a3
R2
R1
l3
b1
l4
A
F
L
I
e
c1
M1
Ø
cooling method: by conduction (c)
Recommended torque value: 0.8 m.N.
Maximum torque value: 1 m.N.
2.2mm
2.54mm
1mm
3.1mm
PRINTED CIRCUIT LAYOUT FOR F5 LAYOUT
®
DMV series
8/9
